SMART GUARD RFID

ORDER NOW

Controls one selected partition

LED indication for recognised or rejected card

LED indication for current ARM/DISARM state





RFID-security-systems

LED indication for system bus state

Built-in buzzer for audible alarm with adjustable volume levels

Built-in tamper for additional security



Product video:


Description:

SG RFID is a proximity reader for access control. The device is compatible only with SMART GUARD alarm panels. It contains one zone, which can be freely connected and one PGM output, which can directly control electromagnetic locks in normal or Smart Door Control (SDC) mode. Work with RFID cards on 125kHz.


Technical Parameters:

  • Power Supply:

9 ÷ 18VDC

  • Power Consumption:

min 15mA, max 60mA

  • Built-in RFID reader:

Yes

  • Range:

Up to 5 cm

  • Zones:

1 zone

  • PGM:

1 PGM, 2A max

  • Built-in Tamper:

Yes

  • Operational Temperature:

from 0˚C to +50˚C

  • Dimensions:

121 mm x 46 mm x 22 mm

Functionality:





SMART HOME

SMART GUARD is a next generation alarm system, combining reliable security and “SMART HOME” automation, allowing the user to easily control different electric and electronic appliances and other external systems through different mobile devices. SMART GUARD has the ability to ARM according to previously set timebased schedules. Implemented Smart Door Control for further automation of electromagnetic locks, without additional power supply modules, reducing time and costs. This makes the SG one of the most innovative, dependable and secure alarm systems on the market!


 CLOUD PLATFORM

SMART GUARD is easily manageable through all mobile platforms. For complete and reliable event monitoring, the system supports simultaneous communication through GSM, Wi-Fi and LAN networks. The built-in GSM communicator has the full functionality of the SMART DIALER with the ability to alert and notify about events via call and SMS to or from specified numbers. The module further provides the option to view event and alarm history from the keypad, PC, CLOUD SMART GUARD and other platforms and devices.




 DATA ENCRYPTION

SMART GUARD has a built-in algorithm for additional high level code protection, ensuring communication encryption for remote access. In the event of an attempt to breach the system, we’ve engineered a highly intelligent software with automatic counteractive measures. By implementing two-way encryption and removing the option to delete events, the system guarantees advanced data security and integrity. It is impossible to manipulate or delete information, without it being sent to the monitoring centre.




REMOTE SUPPORT

SMART GUARD is a one of a kind system, supporting automatic and remote software updates over different devices such as the panel, keypads, proximity readers, expanders and others. In the event of connection loss, the software updates can resume from their last point of progress resulting in saving data and avoiding dangerous loops. Other than on site, through the keypads or/and PC, it is possible to remotely support and program the system and its components. The innovative SG PIR sensor allows the supporting teams to remotely view its current state, troubleshoot and modify the settings.
